LNE

View range presentation
Overview
Details
Inspiration
Downloads
Variants

Overview

Application Areas
Offices, Hotels and residential, Public spaces, Retail, Education, Health and care
Mounting Type
Recessed
Control Gear Included
Yes
Control Gear
LED driver 220-240VAC-50/60Hz
Body Material
Extruded aluminium profile
Frame Material
Extruded aluminium profile
Finishing
Powder-coated

Details

Frame with click system
Frame with click system

Inspiration

Downloads

To download product files, please log in or register here
Main Product Picture
.jpg
Product Pictures
.zip
Application Pictures
.zip
Dimensional Drawing JPG
.jpg
Dimensional Drawing EPS
.eps
Catalogue Pages
.pdf

LNE

Results
80 Products

Filter Variants

Results
Filter Variants
Optical System
Power (W)
Luminous Flux (lm)
Efficiency (lm/W)
UGR
Colour Temperature (CCT)
Dimming
Emergency (h)
Length (mm)
Width (mm)
Clear Filters
Filters
Code
Optical System W lm Output lm/W UGR CCT (K) Dimming Emergency (h) L (mm) W (mm) Recessed (mm)
Code
Optical System W lm Output lm/W UGR CCT (K) Dimming Emergency (h) L (mm) W (mm) Recessed (mm)
90827L063EW0000 DAM - Microprismatic diffuser 18 2113 117 <19 4000 ON/OFF 0 597 297 582x282
90827L063EW0300 DAM - Microprismatic diffuser 18 2019 112 <19 3000 ON/OFF 0 597 297 582x282
90827L063EW3000 DAM - Microprismatic diffuser 18 2113 117 <19 4000 ON/OFF 3 597 297 582x282
90827L063EW3300 DAM - Microprismatic diffuser 18 2019 112 <19 3000 ON/OFF 3 597 297 582x282
90827L063HW0000 DAM - Microprismatic diffuser 19 2113 111 <19 4000 DALI 2 0 597 297 582x282
90827L063HW0300 DAM - Microprismatic diffuser 19 2019 106 <19 3000 DALI 2 0 597 297 582x282
90827L063HW3000 DAM - Microprismatic diffuser 19 2113 111 <19 4000 DALI 2 3 597 297 582x282
90827L063HW3300 DAM - Microprismatic diffuser 19 2019 106 <19 3000 DALI 2 3 597 297 582x282
90827L066EW0000 DAM - Microprismatic diffuser 34 4225 124 <19 4000 ON/OFF 0 597 597 582x582
90827L066EW0300 DAM - Microprismatic diffuser 34 4038 119 <19 3000 ON/OFF 0 597 597 582x582
90827L066EW3000 DAM - Microprismatic diffuser 34 4225 124 <19 4000 ON/OFF 3 597 597 582x582
90827L066EW3300 DAM - Microprismatic diffuser 34 4038 119 <19 3000 ON/OFF 3 597 597 582x582
90827L066HW0000 DAM - Microprismatic diffuser 34 4225 124 <19 4000 DALI 2 0 597 597 582x582
90827L066HW0300 DAM - Microprismatic diffuser 34 4038 119 <19 3000 DALI 2 0 597 597 582x582
90827L066HW3000 DAM - Microprismatic diffuser 34 4225 124 <19 4000 DALI 2 3 597 597 582x582
90827L066HW3300 DAM - Microprismatic diffuser 34 4038 119 <19 3000 DALI 2 3 597 597 582x582
90827L093EW0000 DAM - Microprismatic diffuser 26 3169 122 <19 4000 ON/OFF 0 897 297 882x282
90827L093EW0300 DAM - Microprismatic diffuser 26 3028 116 <19 3000 ON/OFF 0 897 297 882x282
90827L093EW3000 DAM - Microprismatic diffuser 26 3169 122 <19 4000 ON/OFF 3 897 297 882x282
90827L093EW3300 DAM - Microprismatic diffuser 26 3028 116 <19 3000 ON/OFF 3 897 297 882x282
90827L093HW0000 DAM - Microprismatic diffuser 27 3169 117 <19 4000 DALI 2 0 897 297 882x282
90827L093HW0300 DAM - Microprismatic diffuser 27 3028 112 <19 3000 DALI 2 0 897 297 882x282
90827L093HW3000 DAM - Microprismatic diffuser 27 3169 117 <19 4000 DALI 2 3 897 297 882x282
90827L093HW3300 DAM - Microprismatic diffuser 27 3028 112 <19 3000 DALI 2 3 897 297 882x282
90827L123EW0000 DAM - Microprismatic diffuser 34 4225 124 <19 4000 ON/OFF 0 1197 297 1182x282
90827L123EW0300 DAM - Microprismatic diffuser 34 4038 119 <19 3000 ON/OFF 0 1197 297 1182x282
90827L123EW3000 DAM - Microprismatic diffuser 34 4225 124 <19 4000 ON/OFF 3 1197 297 1182x282
90827L123EW3300 DAM - Microprismatic diffuser 34 4038 119 <19 3000 ON/OFF 3 1197 297 1182x282
90827L123HW0000 DAM - Microprismatic diffuser 34 4225 124 <19 4000 DALI 2 0 1197 297 1182x282
90827L123HW0300 DAM - Microprismatic diffuser 34 4038 119 <19 3000 DALI 2 0 1197 297 1182x282
90827L123HW3000 DAM - Microprismatic diffuser 34 4225 124 <19 4000 DALI 2 3 1197 297 1182x282
90827L123HW3300 DAM - Microprismatic diffuser 34 4038 119 <19 3000 DALI 2 3 1197 297 1182x282
90827L153EW0000 DAM - Microprismatic diffuser 42 5282 126 <19 4000 ON/OFF 0 1497 297 1482x282
90827L153EW0300 DAM - Microprismatic diffuser 42 5047 120 <19 3000 ON/OFF 0 1497 297 1482x282
90827L153EW3000 DAM - Microprismatic diffuser 42 5282 126 <19 4000 ON/OFF 3 1497 297 1482x282
90827L153EW3300 DAM - Microprismatic diffuser 42 5047 120 <19 3000 ON/OFF 3 1497 297 1482x282
90827L153HW0000 DAM - Microprismatic diffuser 42 5282 126 <19 4000 DALI 2 0 1497 297 1482x282
90827L153HW0300 DAM - Microprismatic diffuser 42 5047 120 <19 3000 DALI 2 0 1497 297 1482x282
90827L153HW3000 DAM - Microprismatic diffuser 42 5282 126 <19 4000 DALI 2 3 1497 297 1482x282
90827L153HW3300 DAM - Microprismatic diffuser 42 5047 120 <19 3000 DALI 2 3 1497 297 1482x282
90828L063EW0000 LIGHT+ - Opal diffuser 18 2294 127 <22 4000 ON/OFF 0 597 297 582x282
90828L063EW0300 LIGHT+ - Opal diffuser 18 2192 122 <22 3000 ON/OFF 0 597 297 582x282
90828L063EW3000 LIGHT+ - Opal diffuser 18 2294 127 <22 4000 ON/OFF 3 597 297 582x282
90828L063EW3300 LIGHT+ - Opal diffuser 18 2192 122 <22 3000 ON/OFF 3 597 297 582x282
90828L063HW0000 LIGHT+ - Opal diffuser 19 2294 121 <22 4000 DALI 2 0 597 297 582x282
90828L063HW0300 LIGHT+ - Opal diffuser 19 2192 115 <22 3000 DALI 2 0 597 297 582x282
90828L063HW3000 LIGHT+ - Opal diffuser 19 2294 121 <22 4000 DALI 2 3 597 297 582x282
90828L063HW3300 LIGHT+ - Opal diffuser 19 2192 115 <22 3000 DALI 2 3 597 297 582x282
90828L066EW0000 LIGHT+ - Opal diffuser 34 4587 135 <22 4000 ON/OFF 0 597 597 582x582
90828L066EW0300 LIGHT+ - Opal diffuser 34 4384 129 <22 3000 ON/OFF 0 597 597 582x582
90828L066EW3000 LIGHT+ - Opal diffuser 34 4587 135 <22 4000 ON/OFF 3 597 597 582x582
90828L066EW3300 LIGHT+ - Opal diffuser 34 4384 129 <22 3000 ON/OFF 3 597 597 582x582
90828L066HW0000 LIGHT+ - Opal diffuser 34 4587 135 <22 4000 DALI 2 0 597 597 582x582
90828L066HW0300 LIGHT+ - Opal diffuser 34 4384 129 <22 3000 DALI 2 0 597 597 582x582
90828L066HW3000 LIGHT+ - Opal diffuser 34 4587 135 <22 4000 DALI 2 3 597 597 582x582
90828L066HW3300 LIGHT+ - Opal diffuser 34 4384 129 <22 3000 DALI 2 3 597 597 582x582
90828L093EW0000 LIGHT+ - Opal diffuser 26 3441 132 <22 4000 ON/OFF 0 897 297 882x282
90828L093EW0300 LIGHT+ - Opal diffuser 26 3288 126 <22 3000 ON/OFF 0 897 297 882x282
90828L093EW3000 LIGHT+ - Opal diffuser 26 3441 132 <22 4000 ON/OFF 3 897 297 882x282
90828L093EW3300 LIGHT+ - Opal diffuser 26 3288 126 <22 3000 ON/OFF 3 897 297 882x282
90828L093HW0000 LIGHT+ - Opal diffuser 27 3441 127 <22 4000 DALI 2 0 897 297 882x282
90828L093HW0300 LIGHT+ - Opal diffuser 27 3288 122 <22 3000 DALI 2 0 897 297 882x282
90828L093HW3000 LIGHT+ - Opal diffuser 27 3441 127 <22 4000 DALI 2 3 897 297 882x282
90828L093HW3300 LIGHT+ - Opal diffuser 27 3288 122 <22 3000 DALI 2 3 897 297 882x282
90828L123EW0000 LIGHT+ - Opal diffuser 34 4587 135 <22 4000 ON/OFF 0 1197 297 1182x282
90828L123EW0300 LIGHT+ - Opal diffuser 34 4384 129 <22 3000 ON/OFF 0 1197 297 1182x282
90828L123EW3000 LIGHT+ - Opal diffuser 34 4587 135 <22 4000 ON/OFF 3 1197 297 1182x282
90828L123EW3300 LIGHT+ - Opal diffuser 34 4384 129 <22 3000 ON/OFF 3 1197 297 1182x282
90828L123HW0000 LIGHT+ - Opal diffuser 34 4587 135 <22 4000 DALI 2 0 1197 297 1182x282
90828L123HW0300 LIGHT+ - Opal diffuser 34 4384 129 <22 3000 DALI 2 0 1197 297 1182x282
90828L123HW3000 LIGHT+ - Opal diffuser 34 4587 135 <22 4000 DALI 2 3 1197 297 1182x282
90828L123HW3300 LIGHT+ - Opal diffuser 34 4384 129 <22 3000 DALI 2 3 1197 297 1182x282
90828L153EW0000 LIGHT+ - Opal diffuser 42 5734 137 <22 4000 ON/OFF 0 1497 297 1482x282
90828L153EW0300 LIGHT+ - Opal diffuser 42 5480 130 <22 3000 ON/OFF 0 1497 297 1482x282
90828L153EW3000 LIGHT+ - Opal diffuser 42 5734 137 <22 4000 ON/OFF 3 1497 297 1482x282
90828L153EW3300 LIGHT+ - Opal diffuser 42 5480 130 <22 3000 ON/OFF 3 1497 297 1482x282
90828L153HW0000 LIGHT+ - Opal diffuser 42 5734 137 <22 4000 DALI 2 0 1497 297 1482x282
90828L153HW0300 LIGHT+ - Opal diffuser 42 5480 130 <22 3000 DALI 2 0 1497 297 1482x282
90828L153HW3000 LIGHT+ - Opal diffuser 42 5734 137 <22 4000 DALI 2 3 1497 297 1482x282
90828L153HW3300 LIGHT+ - Opal diffuser 42 5480 130 <22 3000 DALI 2 3 1497 297 1482x282
