Indelague

Overview

Application Areas
Public spaces, Industry, Outside
Mounting Type
Surface mounted, Suspended, Wall mounted
Control Gear Included
Yes
Control Gear
LED driver 220-240VAC-50/60Hz
Body Material
Polycarbonate tube
Finishing
Powder-coated
Current Supply Cable Entry Point
End cap
Fixing System
Clamp

Inspiration

TTP 70 LINE

Results
160 Products

Filter Variants

Results
Filter Variants
Module
Optical System
Power (W)
Luminous Flux (lm)
Efficiency (lm/W)
Colour Temperature (CCT)
Dimming
Length (mm)
Options
Clear Filters
Filters
Code
Module Optical System W lm Output lm/W CCT (K) Dimming L (mm) Options
Code
Module Optical System W lm Output lm/W CCT (K) Dimming L (mm) Options
90486L060E00050 End (END) TOP - Opal diffuser 26 3506 135 4000 ON/OFF 620 Polycarbonate end caps
90486L060E00058 Start / Middle (SRT/MID) TOP - Opal diffuser 26 3506 135 4000 ON/OFF 620 Polycarbonate end caps
90486L060E00350 End (END) TOP - Opal diffuser 26 3358 129 3000 ON/OFF 620 Polycarbonate end caps
90486L060E00358 Start / Middle (SRT/MID) TOP - Opal diffuser 26 3358 129 3000 ON/OFF 620 Polycarbonate end caps
90486L060E04049 Start (SRT) TOP - Opal diffuser 26 3506 135 4000 ON/OFF 835 Polycarbonate end caps + Sensor
90486L060E04349 Start (SRT) TOP - Opal diffuser 26 3358 129 3000 ON/OFF 835 Polycarbonate end caps + Sensor
90486L060H00050 End (END) TOP - Opal diffuser 27 3506 130 4000 DALI 2 620 Polycarbonate end caps
90486L060H00058 Start / Middle (SRT/MID) TOP - Opal diffuser 27 3506 130 4000 DALI 2 620 Polycarbonate end caps
90486L060H00350 End (END) TOP - Opal diffuser 27 3358 124 3000 DALI 2 620 Polycarbonate end caps
90486L060H00358 Start / Middle (SRT/MID) TOP - Opal diffuser 27 3358 124 3000 DALI 2 620 Polycarbonate end caps
90486L090E00050 End (END) TOP - Opal diffuser 40 5259 131 4000 ON/OFF 900 Polycarbonate end caps
90486L090E00058 Start / Middle (SRT/MID) TOP - Opal diffuser 40 5259 131 4000 ON/OFF 900 Polycarbonate end caps
90486L090E00350 End (END) TOP - Opal diffuser 40 5037 126 3000 ON/OFF 900 Polycarbonate end caps
90486L090E00358 Start / Middle (SRT/MID) TOP - Opal diffuser 40 5037 126 3000 ON/OFF 900 Polycarbonate end caps
90486L090E04049 Start (SRT) TOP - Opal diffuser 40 5259 131 4000 ON/OFF 1115 Polycarbonate end caps + Sensor
90486L090E04349 Start (SRT) TOP - Opal diffuser 40 5037 126 3000 ON/OFF 1115 Polycarbonate end caps + Sensor
90486L090H00050 End (END) TOP - Opal diffuser 39 5259 135 4000 DALI 2 900 Polycarbonate end caps
90486L090H00058 Start / Middle (SRT/MID) TOP - Opal diffuser 39 5259 135 4000 DALI 2 900 Polycarbonate end caps
90486L090H00350 End (END) TOP - Opal diffuser 39 5037 129 3000 DALI 2 900 Polycarbonate end caps
90486L090H00358 Start / Middle (SRT/MID) TOP - Opal diffuser 39 5037 129 3000 DALI 2 900 Polycarbonate end caps
90486L120E00050 End (END) TOP - Opal diffuser 51 7011 137 4000 ON/OFF 1180 Polycarbonate end caps
90486L120E00058 Start / Middle (SRT/MID) TOP - Opal diffuser 51 7011 137 4000 ON/OFF 1180 Polycarbonate end caps
90486L120E00350 End (END) TOP - Opal diffuser 51 6717 132 3000 ON/OFF 1180 Polycarbonate end caps
90486L120E00358 Start / Middle (SRT/MID) TOP - Opal diffuser 51 6717 132 3000 ON/OFF 1180 Polycarbonate end caps
90486L120E04049 Start (SRT) TOP - Opal diffuser 51 7011 137 4000 ON/OFF 1395 Polycarbonate end caps + Sensor
90486L120E04349 Start (SRT) TOP - Opal diffuser 51 6717 132 3000 ON/OFF 1395 Polycarbonate end caps + Sensor
90486L120H00050 End (END) TOP - Opal diffuser 51 7011 137 4000 DALI 2 1180 Polycarbonate end caps
90486L120H00058 Start / Middle (SRT/MID) TOP - Opal diffuser 51 7011 137 4000 DALI 2 1180 Polycarbonate end caps
90486L120H00350 End (END) TOP - Opal diffuser 51 6717 132 3000 DALI 2 1180 Polycarbonate end caps
90486L120H00358 Start / Middle (SRT/MID) TOP - Opal diffuser 51 6717 132 3000 DALI 2 1180 Polycarbonate end caps
90486L150E00050 End (END) TOP - Opal diffuser 63 8764 139 4000 ON/OFF 1460 Polycarbonate end caps
90486L150E00058 Start / Middle (SRT/MID) TOP - Opal diffuser 63 8764 139 4000 ON/OFF 1460 Polycarbonate end caps
90486L150E00350 End (END) TOP - Opal diffuser 63 8396 133 3000 ON/OFF 1460 Polycarbonate end caps
90486L150E00358 Start / Middle (SRT/MID) TOP - Opal diffuser 63 8396 133 3000 ON/OFF 1460 Polycarbonate end caps
90486L150E04049 Start (SRT) TOP - Opal diffuser 63 8764 139 4000 ON/OFF 1675 Polycarbonate end caps + Sensor
90486L150E04349 Start (SRT) TOP - Opal diffuser 63 8396 133 3000 ON/OFF 1675 Polycarbonate end caps + Sensor
90486L150H00050 End (END) TOP - Opal diffuser 63 8764 139 4000 DALI 2 1460 Polycarbonate end caps
90486L150H00058 Start / Middle (SRT/MID) TOP - Opal diffuser 63 8764 139 4000 DALI 2 1460 Polycarbonate end caps
90486L150H00350 End (END) TOP - Opal diffuser 63 8396 133 3000 DALI 2 1460 Polycarbonate end caps
90486L150H00358 Start / Middle (SRT/MID) TOP - Opal diffuser 63 8396 133 3000 DALI 2 1460 Polycarbonate end caps
90487L060E00050 End (END) TUP - Transparent diffuser 26 3765 145 4000 ON/OFF 620 Polycarbonate end caps
90487L060E00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 26 3765 145 4000 ON/OFF 620 Polycarbonate end caps
90487L060E00350 End (END) TUP - Transparent diffuser 26 3607 139 3000 ON/OFF 620 Polycarbonate end caps
90487L060E00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 26 3607 139 3000 ON/OFF 620 Polycarbonate end caps
90487L060E04049 Start (SRT) TUP - Transparent diffuser 26 3765 145 4000 ON/OFF 835 Polycarbonate end caps + Sensor
90487L060E04349 Start (SRT) TUP - Transparent diffuser 26 3607 139 3000 ON/OFF 835 Polycarbonate end caps + Sensor
90487L060H00050 End (END) TUP - Transparent diffuser 27 3765 139 4000 DALI 2 620 Polycarbonate end caps
90487L060H00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 27 3765 139 4000 DALI 2 620 Polycarbonate end caps
90487L060H00350 End (END) TUP - Transparent diffuser 27 3607 134 3000 DALI 2 620 Polycarbonate end caps
90487L060H00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 27 3607 134 3000 DALI 2 620 Polycarbonate end caps
90487L090E00050 End (END) TUP - Transparent diffuser 40 5648 141 4000 ON/OFF 900 Polycarbonate end caps
90487L090E00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 40 5648 141 4000 ON/OFF 900 Polycarbonate end caps
90487L090E00350 End (END) TUP - Transparent diffuser 40 5411 135 3000 ON/OFF 900 Polycarbonate end caps
90487L090E00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 40 5411 135 3000 ON/OFF 900 Polycarbonate end caps
90487L090E04049 Start (SRT) TUP - Transparent diffuser 40 5648 141 4000 ON/OFF 1115 Polycarbonate end caps + Sensor
90487L090E04349 Start (SRT) TUP - Transparent diffuser 40 5411 135 3000 ON/OFF 1115 Polycarbonate end caps + Sensor
90487L090H00050 End (END) TUP - Transparent diffuser 39 5648 145 4000 DALI 2 900 Polycarbonate end caps
90487L090H00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 39 5648 145 4000 DALI 2 900 Polycarbonate end caps
90487L090H00350 End (END) TUP - Transparent diffuser 39 5411 139 3000 DALI 2 900 Polycarbonate end caps
90487L090H00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 39 5411 139 3000 DALI 2 900 Polycarbonate end caps
90487L120E00050 End (END) TUP - Transparent diffuser 51 7531 148 4000 ON/OFF 1180 Polycarbonate end caps
90487L120E00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 51 7531 148 4000 ON/OFF 1180 Polycarbonate end caps
90487L120E00350 End (END) TUP - Transparent diffuser 51 7214 141 3000 ON/OFF 1180 Polycarbonate end caps
90487L120E00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 51 7214 141 3000 ON/OFF 1180 Polycarbonate end caps
90487L120E04049 Start (SRT) TUP - Transparent diffuser 51 7531 148 4000 ON/OFF 1395 Polycarbonate end caps + Sensor
90487L120E04349 Start (SRT) TUP - Transparent diffuser 51 7214 141 3000 ON/OFF 1395 Polycarbonate end caps + Sensor
90487L120H00050 End (END) TUP - Transparent diffuser 51 7531 148 4000 DALI 2 1180 Polycarbonate end caps
90487L120H00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 51 7531 148 4000 DALI 2 1180 Polycarbonate end caps
90487L120H00350 End (END) TUP - Transparent diffuser 51 7214 141 3000 DALI 2 1180 Polycarbonate end caps
90487L120H00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 51 7214 141 3000 DALI 2 1180 Polycarbonate end caps
90487L150E00050 End (END) TUP - Transparent diffuser 63 9413 149 4000 ON/OFF 1460 Polycarbonate end caps
90487L150E00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 63 9413 149 4000 ON/OFF 1460 Polycarbonate end caps
90487L150E00350 End (END) TUP - Transparent diffuser 63 9018 143 3000 ON/OFF 1460 Polycarbonate end caps
90487L150E00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 63 9018 143 3000 ON/OFF 1460 Polycarbonate end caps
90487L150E04049 Start (SRT) TUP - Transparent diffuser 63 9413 149 4000 ON/OFF 1675 Polycarbonate end caps + Sensor
90487L150E04349 Start (SRT) TUP - Transparent diffuser 63 9018 143 3000 ON/OFF 1675 Polycarbonate end caps + Sensor
90487L150H00050 End (END) TUP - Transparent diffuser 63 9413 149 4000 DALI 2 1460 Polycarbonate end caps
90487L150H00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 63 9413 149 4000 DALI 2 1460 Polycarbonate end caps
90487L150H00350 End (END) TUP - Transparent diffuser 63 9018 143 3000 DALI 2 1460 Polycarbonate end caps
90487L150H00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 63 9018 143 3000 DALI 2 1460 Polycarbonate end caps
90488L060E00050 End (END) TOP - Opal diffuser 12 1691 141 4000 ON/OFF 620 Polycarbonate end caps
90488L060E00058 Start / Middle (SRT/MID) TOP - Opal diffuser 12 1691 141 4000 ON/OFF 620 Polycarbonate end caps
90488L060E00350 End (END) TOP - Opal diffuser 12 1620 135 3000 ON/OFF 620 Polycarbonate end caps
90488L060E00358 Start / Middle (SRT/MID) TOP - Opal diffuser 12 1620 135 3000 ON/OFF 620 Polycarbonate end caps
90488L060E04049 Start (SRT) TOP - Opal diffuser 12 1691 141 4000 ON/OFF 835 Polycarbonate end caps + Sensor
90488L060E04349 Start (SRT) TOP - Opal diffuser 12 1620 135 3000 ON/OFF 835 Polycarbonate end caps + Sensor
90488L060H00050 End (END) TOP - Opal diffuser 12 1691 141 4000 DALI 2 620 Polycarbonate end caps
90488L060H00058 Start / Middle (SRT/MID) TOP - Opal diffuser 12 1691 141 4000 DALI 2 620 Polycarbonate end caps
90488L060H00350 End (END) TOP - Opal diffuser 12 1620 135 3000 DALI 2 620 Polycarbonate end caps
90488L060H00358 Start / Middle (SRT/MID) TOP - Opal diffuser 12 1620 135 3000 DALI 2 620 Polycarbonate end caps
90488L090E00050 End (END) TOP - Opal diffuser 17 2536 149 4000 ON/OFF 900 Polycarbonate end caps
90488L090E00058 Start / Middle (SRT/MID) TOP - Opal diffuser 17 2536 149 4000 ON/OFF 900 Polycarbonate end caps
90488L090E00350 End (END) TOP - Opal diffuser 17 2430 143 3000 ON/OFF 900 Polycarbonate end caps
90488L090E00358 Start / Middle (SRT/MID) TOP - Opal diffuser 17 2430 143 3000 ON/OFF 900 Polycarbonate end caps
90488L090E04049 Start (SRT) TOP - Opal diffuser 17 2536 149 4000 ON/OFF 1115 Polycarbonate end caps + Sensor
90488L090E04349 Start (SRT) TOP - Opal diffuser 17 2430 143 3000 ON/OFF 1115 Polycarbonate end caps + Sensor
90488L090H00050 End (END) TOP - Opal diffuser 17 2536 149 4000 DALI 2 900 Polycarbonate end caps
90488L090H00058 Start / Middle (SRT/MID) TOP - Opal diffuser 17 2536 149 4000 DALI 2 900 Polycarbonate end caps
90488L090H00350 End (END) TOP - Opal diffuser 17 2430 143 3000 DALI 2 900 Polycarbonate end caps
90488L090H00358 Start / Middle (SRT/MID) TOP - Opal diffuser 17 2430 143 3000 DALI 2 900 Polycarbonate end caps
90488L120E00050 End (END) TOP - Opal diffuser 21 3382 161 4000 ON/OFF 1180 Polycarbonate end caps
90488L120E00058 Start / Middle (SRT/MID) TOP - Opal diffuser 21 3382 161 4000 ON/OFF 1180 Polycarbonate end caps
90488L120E00350 End (END) TOP - Opal diffuser 21 3240 154 3000 ON/OFF 1180 Polycarbonate end caps
90488L120E00358 Start / Middle (SRT/MID) TOP - Opal diffuser 21 3240 154 3000 ON/OFF 1180 Polycarbonate end caps
90488L120E04049 Start (SRT) TOP - Opal diffuser 21 3382 161 4000 ON/OFF 1395 Polycarbonate end caps + Sensor
90488L120E04349 Start (SRT) TOP - Opal diffuser 21 3240 154 3000 ON/OFF 1395 Polycarbonate end caps + Sensor
90488L120H00050 End (END) TOP - Opal diffuser 22 3382 154 4000 DALI 2 1180 Polycarbonate end caps
90488L120H00058 Start / Middle (SRT/MID) TOP - Opal diffuser 22 3382 154 4000 DALI 2 1180 Polycarbonate end caps
90488L120H00350 End (END) TOP - Opal diffuser 22 3240 147 3000 DALI 2 1180 Polycarbonate end caps
90488L120H00358 Start / Middle (SRT/MID) TOP - Opal diffuser 22 3240 147 3000 DALI 2 1180 Polycarbonate end caps
90488L150E00050 End (END) TOP - Opal diffuser 26 4227 163 4000 ON/OFF 1460 Polycarbonate end caps
90488L150E00058 Start / Middle (SRT/MID) TOP - Opal diffuser 26 4227 163 4000 ON/OFF 1460 Polycarbonate end caps
90488L150E00350 End (END) TOP - Opal diffuser 26 4051 156 3000 ON/OFF 1460 Polycarbonate end caps
90488L150E00358 Start / Middle (SRT/MID) TOP - Opal diffuser 26 4051 156 3000 ON/OFF 1460 Polycarbonate end caps
90488L150E04049 Start (SRT) TOP - Opal diffuser 26 4227 163 4000 ON/OFF 1675 Polycarbonate end caps + Sensor
90488L150E04349 Start (SRT) TOP - Opal diffuser 26 4051 156 3000 ON/OFF 1675 Polycarbonate end caps + Sensor
90488L150H00050 End (END) TOP - Opal diffuser 28 4227 151 4000 DALI 2 1460 Polycarbonate end caps
90488L150H00058 Start / Middle (SRT/MID) TOP - Opal diffuser 28 4227 151 4000 DALI 2 1460 Polycarbonate end caps
90488L150H00350 End (END) TOP - Opal diffuser 28 4051 145 3000 DALI 2 1460 Polycarbonate end caps
90488L150H00358 Start / Middle (SRT/MID) TOP - Opal diffuser 28 4051 145 3000 DALI 2 1460 Polycarbonate end caps
90489L060E00050 End (END) TUP - Transparent diffuser 12 1789 149 4000 ON/OFF 620 Polycarbonate end caps
90489L060E00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 12 1789 149 4000 ON/OFF 620 Polycarbonate end caps
90489L060E00350 End (END) TUP - Transparent diffuser 12 1714 143 3000 ON/OFF 620 Polycarbonate end caps
90489L060E00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 12 1714 143 3000 ON/OFF 620 Polycarbonate end caps
90489L060E04049 Start (SRT) TUP - Transparent diffuser 12 1789 149 4000 ON/OFF 835 Polycarbonate end caps + Sensor
90489L060E04349 Start (SRT) TUP - Transparent diffuser 12 1714 143 3000 ON/OFF 835 Polycarbonate end caps + Sensor
90489L060H00050 End (END) TUP - Transparent diffuser 12 1789 149 4000 DALI 2 620 Polycarbonate end caps
90489L060H00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 12 1789 149 4000 DALI 2 620 Polycarbonate end caps
90489L060H00350 End (END) TUP - Transparent diffuser 12 1714 143 3000 DALI 2 620 Polycarbonate end caps
90489L060H00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 12 1714 143 3000 DALI 2 620 Polycarbonate end caps
90489L090E00050 End (END) TUP - Transparent diffuser 17 2684 158 4000 ON/OFF 900 Polycarbonate end caps
90489L090E00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 17 2684 158 4000 ON/OFF 900 Polycarbonate end caps
90489L090E00350 End (END) TUP - Transparent diffuser 17 2572 151 3000 ON/OFF 900 Polycarbonate end caps
90489L090E00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 17 2572 151 3000 ON/OFF 900 Polycarbonate end caps
90489L090E04049 Start (SRT) TUP - Transparent diffuser 17 2684 158 4000 ON/OFF 1115 Polycarbonate end caps + Sensor
90489L090E04349 Start (SRT) TUP - Transparent diffuser 17 2572 151 3000 ON/OFF 1115 Polycarbonate end caps + Sensor
90489L090H00050 End (END) TUP - Transparent diffuser 17 2684 158 4000 DALI 2 900 Polycarbonate end caps
90489L090H00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 17 2684 158 4000 DALI 2 900 Polycarbonate end caps
90489L090H00350 End (END) TUP - Transparent diffuser 17 2572 151 3000 DALI 2 900 Polycarbonate end caps
90489L090H00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 17 2572 151 3000 DALI 2 900 Polycarbonate end caps
90489L120E00050 End (END) TUP - Transparent diffuser 21 3578 170 4000 ON/OFF 1180 Polycarbonate end caps
90489L120E00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 21 3578 170 4000 ON/OFF 1180 Polycarbonate end caps
90489L120E00350 End (END) TUP - Transparent diffuser 21 3429 163 3000 ON/OFF 1180 Polycarbonate end caps
90489L120E00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 21 3429 163 3000 ON/OFF 1180 Polycarbonate end caps
90489L120E04049 Start (SRT) TUP - Transparent diffuser 21 3578 170 4000 ON/OFF 1395 Polycarbonate end caps + Sensor
90489L120E04349 Start (SRT) TUP - Transparent diffuser 21 3429 163 3000 ON/OFF 1395 Polycarbonate end caps + Sensor
90489L120H00050 End (END) TUP - Transparent diffuser 22 3578 163 4000 DALI 2 1180 Polycarbonate end caps
90489L120H00058 Start / Middle (SRT/MID) TUP - Transparent diffuser 22 3578 163 4000 DALI 2 1180 Polycarbonate end caps
90489L120H00350 End (END) TUP - Transparent diffuser 22 3429 156 3000 DALI 2 1180 Polycarbonate end caps
90489L120H00358 Start / Middle (SRT/MID) TUP - Transparent diffuser 22 3429 156 3000 DALI 2 1180 Polycarbonate end caps
Explore our products
Go to Products
Title Cookie Settings

INDELAGUE may use cookies to memorize your login data, collect statistics to optimize the website’s functionality and to carry out marketing actions based on your interests.You can customize used cookies in .

Options to able or disable cookies by preference.

Strictly Necessary Cookies
These cookies are essential to provide services available on our website and to enable you to use certain features on our website.
Without these cookies, we cannot provide certain services on our site.

Functionality cookies
These cookies are used to provide a more personalised experience on our website and to remember the choices you make when using our website.
For example, we may use functionality cookies to remember your language preferences and/or your login details.

Customization Cookies
These cookies are used to recognise visitors when they return to our site. This allows us to personalise the content of the site for you, greet you by name and remember your preferences (for example, your choice of language or region).

Security Cookies
These cookies are used to protect the security of our website and your data. This includes cookies that are used to allow you to log in to secure areas of our website.

Measurement and Performance Cookies
These cookies are used to collect information to analyse traffic on our site and understand how visitors are using our site.
For example, these cookies can measure factors such as the time spent on the site or the pages visited, this will allow us to understand how we can improve our site for users.
The information collected through these measurement and performance cookies does not identify any individual visitor.

Advertising Cookies
These cookies are used to provide adverts that are more relevant to you and your interests. They are also used to limit the number of times you see an advert and to help measure the effectiveness of an advertising campaign. They may be placed by us or by third parties with our permission. They remember that you have visited a site and this information is shared with other organisations, such as advertisers.
