Optical system
bOPTICS
bOPTICS
Minimalism and technology
1
Body
Extruded aluminum body, available in 2 colors.
2
LED
SDCM MacAdam ≤3, 3000K / 4000K colour temperature, CRI>80 and 80.000h lifetime L80 B10.
3
bOPTICS
High-tech optical system with bOPTICS reflector for high visual comfort lighting (UGR<19).
4
End cap
Aluminum end caps, without light leakage and with no visible screws. Available in the same colour as the product.
5
Suspension and current supply cable
Suspensions and current supply cables available in 1500 mm, 3000 mm or 6000 mm length.
6
Ceiling rose
Ceiling roses in recessed or surface mounted versions, available in black or white colour.
7
Body connector kit
Body connector
Body connector 90°
The two profiles are seamlessly connected so there is no light leakage in any continuous line application.
Structural elements composition
1
LED modules
2
End caps
3
Body connector kit
4
Suspension
5
Current supply cable
