AVT

View range presentation
Overview
Details
Inspiration
Downloads
Variants

Overview

Application Areas
Offices, Hotels and residential, Public spaces, Retail, Education, Health and care
Mounting Type
Recessed
Control Gear Included
Yes
Control Gear
LED driver 220-240VAC-50/60Hz
Body Material
Extruded aluminium profile
Frame Material
Extruded aluminium profile
Finishing
Powder-coated

Details

Lay-in recessed version
Lay-in recessed version

Inspiration

Downloads

To download product files, please log in or register here
Main Product Picture
.jpg
Product Pictures
.zip
Application Pictures
.zip
Dimensional Drawing JPG
.jpg
Dimensional Drawing EPS
.eps
Catalogue Pages
.pdf

AVT

Results
40 Products

Filter Variants

Results
Filter Variants
Optical System
Power (W)
Luminous Flux (lm)
Efficiency (lm/W)
UGR
Dimming
Emergency (h)
Length (mm)
Width (mm)
Clear Filters
Filters
Code
Optical System W lm Output lm/W UGR Dimming Emergency (h) L (mm) W (mm) Recessed (mm)
Code
Optical System W lm Output lm/W UGR Dimming Emergency (h) L (mm) W (mm) Recessed (mm)
90797L066EW0000 DAM - Microprismatic diffuser 34 4104 121 <19 ON/OFF 0 597 597 575x575
90797L066EW3000 DAM - Microprismatic diffuser 34 4104 121 <19 ON/OFF 3 597 597 575x575
90797L066HW0000 DAM - Microprismatic diffuser 34 4104 121 <19 DALI 2 0 597 597 575x575
90797L066HW3000 DAM - Microprismatic diffuser 34 4104 121 <19 DALI 2 3 597 597 575x575
90797L123EW0000 DAM - Microprismatic diffuser 34 4104 121 <19 ON/OFF 0 1197 297 1175x275
90797L123EW3000 DAM - Microprismatic diffuser 34 4104 121 <19 ON/OFF 3 1197 297 1175x275
90797L123HW0000 DAM - Microprismatic diffuser 34 4104 121 <19 DALI 2 0 1197 297 1175x275
90797L123HW3000 DAM - Microprismatic diffuser 34 4104 121 <19 DALI 2 3 1197 297 1175x275
90797L153EW0000 DAM - Microprismatic diffuser 42 5131 122 <19 ON/OFF 0 1497 297 1475x275
90797L153EW3000 DAM - Microprismatic diffuser 42 5131 122 <19 ON/OFF 3 1497 297 1475x275
90797L153HW0000 DAM - Microprismatic diffuser 42 5131 122 <19 DALI 2 0 1497 297 1475x275
90797L153HW3000 DAM - Microprismatic diffuser 42 5131 122 <19 DALI 2 3 1497 297 1475x275
90798L066EW0000 LIGHT+ - Opal diffuser 34 4527 133 <22 ON/OFF 0 597 597 575x575
90798L066EW3000 LIGHT+ - Opal diffuser 34 4527 133 <22 ON/OFF 3 597 597 575x575
90798L066HW0000 LIGHT+ - Opal diffuser 34 4527 133 <22 DALI 2 0 597 597 575x575
90798L066HW3000 LIGHT+ - Opal diffuser 34 4527 133 <22 DALI 2 3 597 597 575x575
90798L123EW0000 LIGHT+ - Opal diffuser 34 4527 133 <22 ON/OFF 0 1197 297 1175x275
90798L123EW3000 LIGHT+ - Opal diffuser 34 4527 133 <22 ON/OFF 3 1197 297 1175x275
90798L123HW0000 LIGHT+ - Opal diffuser 34 4527 133 <22 DALI 2 0 1197 297 1175x275
90798L123HW3000 LIGHT+ - Opal diffuser 34 4527 133 <22 DALI 2 3 1197 297 1175x275
90798L153EW0000 LIGHT+ - Opal diffuser 42 5659 135 <22 ON/OFF 0 1497 297 1475x275
90798L153EW3000 LIGHT+ - Opal diffuser 42 5659 135 <22 ON/OFF 3 1497 297 1475x275
90798L153HW0000 LIGHT+ - Opal diffuser 42 5659 135 <22 DALI 2 0 1497 297 1475x275
90798L153HW3000 LIGHT+ - Opal diffuser 42 5659 135 <22 DALI 2 3 1497 297 1475x275
90799L066EW0000 DAM - Microprismatic diffuser 59 6925 117 <19 ON/OFF 0 597 597 575x575
90799L066EW3000 DAM - Microprismatic diffuser 59 6925 117 <19 ON/OFF 3 597 597 575x575
90799L066HW0000 DAM - Microprismatic diffuser 59 6925 117 <19 DALI 2 0 597 597 575x575
90799L066HW3000 DAM - Microprismatic diffuser 59 6925 117 <19 DALI 2 3 597 597 575x575
90799L153EW0000 DAM - Microprismatic diffuser 74 8656 117 <22 ON/OFF 0 1497 297 1475x275
90799L153EW3000 DAM - Microprismatic diffuser 74 8656 117 <22 ON/OFF 3 1497 297 1475x275
90799L153HW0000 DAM - Microprismatic diffuser 73 8656 119 <22 DALI 2 0 1497 297 1475x275
90799L153HW3000 DAM - Microprismatic diffuser 73 8656 119 <22 DALI 2 3 1497 297 1475x275
90800L066EW0000 LIGHT+ - Opal diffuser 59 7638 129 <25 ON/OFF 0 597 597 575x575
90800L066EW3000 LIGHT+ - Opal diffuser 59 7638 129 <25 ON/OFF 3 597 597 575x575
90800L066HW0000 LIGHT+ - Opal diffuser 59 7638 129 <25 DALI 2 0 597 597 575x575
90800L066HW3000 LIGHT+ - Opal diffuser 59 7638 129 <25 DALI 2 3 597 597 575x575
90800L153EW0000 LIGHT+ - Opal diffuser 74 9548 129 <25 ON/OFF 0 1497 297 1475x275
90800L153EW3000 LIGHT+ - Opal diffuser 74 9548 129 <25 ON/OFF 3 1497 297 1475x275
90800L153HW0000 LIGHT+ - Opal diffuser 73 9548 131 <25 DALI 2 0 1497 297 1475x275
90800L153HW3000 LIGHT+ - Opal diffuser 73 9548 131 <25 DALI 2 3 1497 297 1475x275
