ELI SQ /C

View range presentation
Overview
Inspiration
Downloads
Variants

Overview

Application Areas
Offices, Hotels and residential, Public spaces, Retail, Education, Health and care
Mounting Type
Surface mounted
Control Gear Included
Yes
Control Gear
LED driver 220-240VAC-50/60Hz
Body Material
Extruded aluminium profile
Finishing
Powder-coated
Current Supply Cable Entry Point
Back

Inspiration

Downloads

To download product files, please log in or register here
Main Product Picture
.jpg
Product Pictures
.zip
Application Pictures
.zip
Dimensional Drawing JPG
.jpg
Dimensional Drawing EPS
.zip
Catalogue Pages
.pdf

ELI SQ /C

Results
32 Products

Filter Variants

Results
Filter Variants
Colour
Beam angle
Power (W)
Luminous Flux (lm)
Efficiency (lm/W)
Colour Temperature (CCT)
Dimming
Clear Filters
Filters
Code
Colour Beam angle W lm Output lm/W CCT (K) Dimming
Code
Colour Beam angle W lm Output lm/W CCT (K) Dimming
90598L200EB0035 Black (B) 27° 9 1161 129 4000 ON/OFF
90598L200EB0060 Black (B) 53° 9 1161 129 4000 ON/OFF
90598L200EB0335 Black (B) 27° 9 1062 118 3000 ON/OFF
90598L200EB0360 Black (B) 53° 9 1062 118 3000 ON/OFF
90598L200EW0035 White (W) 27° 9 1161 129 4000 ON/OFF
90598L200EW0060 White (W) 53° 9 1161 129 4000 ON/OFF
90598L200EW0335 White (W) 27° 9 1062 118 3000 ON/OFF
90598L200EW0360 White (W) 53° 9 1062 118 3000 ON/OFF
90598L200HB0035 Black (B) 27° 10 1161 116 4000 DALI 2
90598L200HB0060 Black (B) 53° 10 1161 116 4000 DALI 2
90598L200HB0335 Black (B) 27° 10 1062 106 3000 DALI 2
90598L200HB0360 Black (B) 53° 10 1062 106 3000 DALI 2
90598L200HW0035 White (W) 27° 10 1161 116 4000 DALI 2
90598L200HW0060 White (W) 53° 10 1161 116 4000 DALI 2
90598L200HW0335 White (W) 27° 10 1062 106 3000 DALI 2
90598L200HW0360 White (W) 53° 10 1062 106 3000 DALI 2
90672L200EB0035 Black (B) 27° 6 706 118 4000 ON/OFF
90672L200EB0060 Black (B) 53° 6 706 118 4000 ON/OFF
90672L200EB0335 Black (B) 27° 6 663 111 3000 ON/OFF
90672L200EB0360 Black (B) 53° 6 655 109 3000 ON/OFF
90672L200EW0035 White (W) 27° 6 706 118 4000 ON/OFF
90672L200EW0060 White (W) 53° 6 706 118 4000 ON/OFF
90672L200EW0335 White (W) 27° 6 663 111 3000 ON/OFF
90672L200EW0360 White (W) 53° 6 655 109 3000 ON/OFF
90672L200HB0035 Black (B) 27° 6 706 118 4000 DALI 2
90672L200HB0060 Black (B) 53° 6 706 118 4000 DALI 2
90672L200HB0335 Black (B) 27° 6 663 111 3000 DALI 2
90672L200HB0360 Black (B) 53° 6 655 109 3000 DALI 2
90672L200HW0035 White (W) 27° 6 706 118 4000 DALI 2
90672L200HW0060 White (W) 53° 6 706 118 4000 DALI 2
90672L200HW0335 White (W) 27° 6 663 111 3000 DALI 2
90672L200HW0360 White (W) 53° 6 655 109 3000 DALI 2
