OREO OUT D630 BLINE 927 N
90401L6300N0200
Copied to Clipboard
Application Areas
Offices, Hotels and residential, Public spaces, Retail, Education, Health and care
Mounting Type
Suspended
Control Gear Included
No
Luminaire Type
Circular luminaire
Luminaire Module
Individual
Insulation Class
III
Ingress Protection (IP)
40
Ambient Temperature Range (°C)
]-5;25[
Warranty (Years)
5
Body Material
Extruded aluminium profile
Finishing
Epoxy polyester powder coated
Colour
Jungle (N)
Glow-wire Resistance (°C)
850
Optical System
bLINE - Opal diffuser
Light Distribution
Direct
Beam Angle (°)
25
Light Source
LED
Input Power (W)
20
Power Factor (λ)
1
Luminaire Luminous Flux (lm)
1149
Luminaire Efficacy (lm/W)
57
Unified Glare Rating (UGR)
<22
LED Lifetime - Rated Median Useful Life
60.000h @ L80, B10, Ta 25°C
CCT - Correlated Colour Temperature (K)
2700
Photobiological safety according to IEC 62471
Not Available
Colour Rendering Index (CRI)
>90
Chromaticity Tolerance (MacAdam step)
<3
This Product Contains a Light Source of Energy Efficiency Class
F
LED Module Forward Voltage Range (VF)
24V DC
Input luminaire current (mA)
818
H - Height (mm)
35
D - Diameter (mm)
630
Net Weight (kg)
2
Notes:
• Current supply cable/suspension with 1500 mm included;
• To complete the product it is necessary to order the ceiling rose separately;
• For RGB White versions, the product must include a transparent current supply cable.
