CONCEPT O 65 D/I D1500 LIGHT+ DALI 830 1
90636L150H10300
Copied to Clipboard
Application Areas
Architectural, Offices, Hotels and residential, Public spaces, Retail, Art and Culture, Education, Health and care
Mounting Type
Suspended
Control Gear Included
Yes
Control Gear
LED driver 220-240VAC-50/60Hz
Luminaire Type
Circular luminaire
Luminaire Module
Individual
Insulation Class
I
Ingress Protection (IP)
20
Ambient Temperature Range (°C)
]-5;25[
Warranty (Years)
5
Current Supply Cable Entry Point
Back
Body Material
Extruded aluminium profile
Finishing
Epoxy polyester powder coated
Colour
Mist (1)
Glow-wire Resistance (°C)
650
Optical System
LIGHT+ - Opal diffuser
Light Distribution
Direct / Indirect
Beam Angle (°)
102
Light Source
LED
Input Power (W)
112
Input Driver Voltage
220-240V-50/60Hz
Power Factor (λ)
0,99
Luminaire Luminous Flux (lm)
11639
Luminaire Efficacy (lm/W)
104
Unified Glare Rating (UGR)
<19
LED Lifetime - Rated Median Useful Life
80.000h @ L90, B10, Ta 25°C
CCT - Correlated Colour Temperature (K)
3000
Colour Rendering Index (CRI)
>80
Chromaticity Tolerance (MacAdam step)
<3
LED Module Forward Voltage Range (VF)
2,7
Power Supply Dimming
DALI 2
Central Battery Emergency Lighting System (VDC)
176-280
Maximum of Luminaires by Magnetic Circuit Breaker B16
<22
Inrush Current (A)
46
Pulse Duration (µs)
240
W - Width (mm)
65
H - Height (mm)
85
D - Diameter (mm)
1500
Notes:
• To complete the product it is necessary to order the suspension, the current supply cable and ceiling rose. Please order separately;
• In order to guarantee a total uniformity of light on the ceiling, the installation must be done at a minimum distance of 500 mm.
