CAB L12W36 WIDE HF 840 W
90851L123EW0000
Copied to Clipboard
Application Areas
Offices, Hotels and residential, Public spaces, Retail, Education, Health and care
Mounting Type
Surface mounted, Suspended
Control Gear Included
Yes
Control Gear
LED driver 220-240VAC-50/60Hz
Notes
• To complete the product it is necessary to order the fixation system separately.
Luminaire Type
Rectangular luminaire
Luminaire Module
Individual
Insulation Class
I
Ingress Protection (IP)
65
Mechanical Impact Protection (IK)
09
Ambient Temperature Range (°C)
]-5;25[
Warranty (Years)
5
Current Supply Cable Entry Point
Back
Body Material
Steel sheet
Frame Material
Extruded aluminium profile
Finishing
Epoxy polyester powder coated
Colour
White (W)
Glow-wire Resistance (°C)
960
Optical System
Wide - wide beam angle
Light Distribution
Direct
Beam Angle (°)
90
Light Source
LED
Input Power (W)
136
Input Driver Voltage
220-240V-50/60Hz
Power Factor (λ)
0,98
Luminaire Luminous Flux (lm)
22655
Luminaire Efficacy (lm/W)
167
Unified Glare Rating (UGR)
<19
LED Lifetime - Rated Median Useful Life
80.000h @ L80, B10, Ta 25°C
CCT - Correlated Colour Temperature (K)
4000
Colour Rendering Index (CRI)
>80
Chromaticity Tolerance (MacAdam step)
<3
LED Module Forward Voltage Range (VF)
30,6
Power Supply Dimming
ON/OFF
Central Battery Emergency Lighting System (VDC)
176-280
Maximum of Luminaires by Magnetic Circuit Breaker B16
<7
Inrush Current (A)
41
Pulse Duration (µs)
236
L - Length (mm)
1250
W - Width (mm)
365
H - Height (mm)
82
D - Recess Dimensions (mm)
1294x411
H - Recess Height (mm)
92
Net Weight (kg)
11.4
