TEI L60W60 DCS DALI 830 W HO
90852L060HW0300
Copied to Clipboard
Application Areas
Offices, Hotels and residential, Public spaces, Retail, Education, Health and care
Mounting Type
Recessed
Control Gear Included
Yes
Control Gear
LED driver 220-240VAC-50/60Hz
Luminaire Type
Square luminaire
Luminaire Module
Individual
Insulation Class
I
Ingress Protection (IP)
20
Ambient Temperature Range (°C)
]-5;25[
Warranty (Years)
5
Current Supply Cable Entry Point
Back
Body Material
Steel sheet
Finishing
Epoxy polyester powder coated
Colour
White (W)
Glow-wire Resistance (°C)
650
Optical System
DCS - Microperforated diffuser
Light Distribution
Direct
Beam Angle (°)
136
Light Source
LED
Input Power (W)
44
Input Driver Voltage
220-240V-50/60Hz
Power Factor (λ)
0,97
Luminaire Luminous Flux (lm)
3186
Luminaire Efficacy (lm/W)
72
Unified Glare Rating (UGR)
<22
LED Lifetime - Rated Median Useful Life
80.000h @ L90, B10, Ta 25°C
CCT - Correlated Colour Temperature (K)
3000
Colour Rendering Index (CRI)
>80
Chromaticity Tolerance (MacAdam step)
<3
This Product Contains a Light Source of Energy Efficiency Class
C
LED Module Forward Voltage Range (VF)
34,2
Power Supply Dimming
DALI 2
Central Battery Emergency Lighting System (VDC)
176-280
Maximum of Luminaires by Magnetic Circuit Breaker B16
<30
Inrush Current (A)
25
Pulse Duration (µs)
177
L - Length (mm)
595
W - Width (mm)
595
H - Height (mm)
95
D - Recess Dimensions (mm)
578x578
H - Recess Height (mm)
95
